Equipment rent

• Mobile scenic complex

  The Prolyte mobile stage complex. This is a unique collapsible structure that has no analogues in the Republic of Belarus.

  A mobile stage complex is a mobile concert stage equipped with sound, lighting and video projection equipment, the installation of which requires no more than two days.

  This stage complex is designed for organizing and conducting show programs, presentations, large corporate events, promotions, city holidays, etc. The Palace provides full technical support for concert and entertainment events: staging and maintenance of a Mobile stage complex, setting up and operation of sound and lighting equipment.

  Technical characteristics

  Stage	Two variants: 1.     Width 20m and depth 14m. 2.     Width 12m and depth 10m.
  Large-sized roof structure	Roof system ST. Rigid modular construction made of aluminum trusses. The elevator roof is raised by means of 8 electric winches. All winches have the ability to connect to a single controller. The cross-shaped roof module provides additional rigidity and stability and allows you to hang a variety of lighting and sound equipment in accordance with the scheme of concerts and other entertainment events.
  Connecting tower trusses	The maximum length is 11.5 m (up to the ridge 14.7 m).
  Stage platform	It can be installed at a height of 90 cm to 210 cm from ground level.
  Inclined overpass	It has an anti-slip cover for transporting various equipment, musical instruments, etc. to and from the stage.
  Tower	A free-standing, weather-protected tower with sound and light control panels, LED dynamics and sound.
  Two small towers	Designed for television cameras and tracking spotlights from stairs.

  • The steel bases of the towers have rigidly fixed spacers, 4 spacers each.
  • The scenic design of the mobile stage complex has the ability to be used both outdoors and indoors.
  • The unified system of connecting nodes allows you to get almost any configuration of the stage platform, carry out its further expansion, add additional elements (ladders, safety railings, etc.).
  • The structural elements do not require the use of lifting equipment during installation.
  • To install a stage complex on a lawn, sand or other unstable ground, there is a set of foundation rigidity elements.
  • Anti-slip podium cover.



• Hanging structure for LED screen (included)

  The Palace of the Republic is ready to provide you with an original design for hanging an LED screen manufactured by Wilhelm Layher GmbH & Co KG, Germany.

  The structure is a spatial universal frame structure made of unified modular elements with a wedge connection, made of galvanized steel, to accommodate light (LED screens), sound and other equipment with a total payload of 20,000 kg. The design consists of elements of the same type, the installation dimensions of which allow, if necessary, to assemble structures of various configurations with a multiplicity of 2.07 m, a height step of 0.5 m.

  Suspension beams provide the use of winches both by fixing them directly on the beam, and by fixing them at a distance. The structures are easy to assemble and disassemble, require a minimum of time for installation.

  The base of the structure provides the possibility of its installation on an uneven surface, with adjustment of the height of the supports and weight.

  Structural elements do not require the use of lifting equipment during installation.

  Can be used both outdoors and indoors.

  The trained staff of the Palace of the Republic will carry out detailed designs for specific customer equipment using specialized software for the design of various non-standard design options.

  When ordering stage structures from us, you get an impeccably worked out event that meets all technical and safety standards, which guarantees the success of your event, taking into account the concept and your wishes.



• Stage equipment

  Electric chain winch ChainMaster RigginLift BGV-D8 in the amount of 12 pieces:

  • capacity 320 kg;
  • chain length 28 m;
  • double brake;
  • supply voltage 380V;
  • lifting (lowering) speed – 4 m/min.



  Electric chain winch (chain 28 meters), art. SL10 1004 m2 A D8+, manufactured by Verlinde, France, in the amount of 40 pcs.:

  • capacity 1 ton;
  • chain length 28 m;
  • double brake;
  • supply voltage 380V;
  • lifting (lowering) speed – 4 m/min.



  Electric chain winches PROLYFT PLE-12-027 in the amount of 32 pieces:

  • • capacity 1 ton;
    • chain length 27 m;
    • supply voltage 380V;
    • lifting (lowering) speed – 4 m/min.



  Electric chain winches PROLYFT PLE-10-027 in the amount of 6 pieces:

  • capacity 250 kg;
  • chain length 27 m;
  • supply voltage 380V;
  • lifting (lowering) speed – 4 m/min.



  Controllers 8-channel PLE-30-080 in the amount of 3 pieces for controlling eight winches simultaneously.
  Controllers 2-channel PLE-30-020 in the amount of 8 pieces for simultaneous control of two winches.


  TE-086 Lift Stand Prolifts S.L. for the installation of stage equipment in the amount of 16 pieces, complete with adjustable truss mount with folding clamp PSA-01 and adjustable truss mount PSD-01.


  • load capacity (maximum load) – 300 kg;
  • maximum height – 6.5 m;
  • height when folded – 1.87 m;
  • weight -129 kg;
  • base overall dimensions – 2.3 x 2.3 m;
  • security system – ALS – auto-locking: fixing the section at the required height, blocking the lift and preventing the lift from tipping over with the load;
  • built-in wheels for easy transport;
  • material – steel (black color).

  Podium tables 200×100 cm, height from 20 cm to 210 cm. For mounting scenes of different configurations.




  Farm aluminum 40×40, different lengths.


  Farm radius 40×40, diameter 4 m and 8 m.


• Sound

  List of equipment offered for rent (docx)

  Big hall Equipment

  Main sound reinforcement system

  A 3-way speaker system is constituted by the set Xlc 127DVX, Xlc 215, EV Xsub(F) Line Array – a linear array from a world-known manufacturer – the firm “Electro-Voice”.

  The system is equipped P3000RL type boosters and universal digital processors for EV DX-38 type sound systems, ensuring homogenous +/- 6db) sound pressure in the whole auditorium in the frequency diapason of 15Hz – 20kHz without any distortions.

  Rated capacity of the sound reinforcement system is – 80kW (2x40kW).

  Equalization of sound is carried out by the devices Klark Teknik DN370 – graphic, 2-way, 30-band-pass, 1/3 octave, analogue with 3U filters.

  Main sound engineer console

  Main (F.O.H.) sound engineer console by Midas «Heritage 3000» – an international standard console, has 56 channels, of which: 52 mono + 4 stereo ins + 24 aux/mix + 8 matrix.

  Peculiarities:

  • 4-way fully parametric equalizer;
  • Direct Out switch on the front panel;
  • 10 VCA,
  • 10 auto-mute groups;
  • matrix 27?8.

  Monitoring stage console

  Monitoring stage console – Midas “Heritage 4000” – allows to make up to 40 mixed and one stereo master.

  Heritage 4000 has 56 channels, of which:
  52 mono/4 stereo ins.

  Peculiarities:

  Heritage 4000 has 56 channels, of which:
  52 mono/4 stereo ins.

  Peculiarities:

  • 4-way fully parametric equalizer;
  • Direct Out switch on the front panel;
  • 10 VCA,
  • 10 auto-mute groups;
  • matrix 27×8.

  Sound processing equipment

  Dynamic sound processing devices and effects processors – by the following manufacturers: dbx, tc-electronic, Drawmer, XTA, BSS, Lexicon (compressors, limiters, noise dampers, gates).

  Monitor system

  Monitor system is constituted by the set (Electro-Voice) of PX2122, PX2152, PX2181 and PX2152 type with amplifiers of capacity of CP4000S type, digital processors of the type EV DX38 and Klark Teknik DN370 equalizers.

  Rated capacity – 8kW.

  Additional equipment

  Bass guitar combo – B-115E with amplifier Ampeg SVT-3PRO; Trace Elliot.

  Guitar combos:

  • cabinet Marshall 1960A with amplifier Marshall JCM900;
  • cabinet Fender ’65 TWiN REVERB;
  • cabinet Trace Elliot;
  • CD- and MD-players by “Tascam” in a sufficient amount.

  Small Hall equipment

  Main sound reinforcement system

  A 3-way acoustic system is constituted by the set SP128S, VS3218-9 and VS2210-9 by a worls-known manufacturer “JBL” and is equipped with amplifiers of capacity of a famous firm “Crest Audio” of the following types: 9001, 8001, 4601, 7001, CKX300, JBL MPX600 and a controller JBL DSC280.

  The installed equipment ensures homogeneous sound pressure in the whole auditorium in the frequency diapason of 20Hz – 20kHz without distortions.

  Rated capacity of the sound reinforcement system – 18kW (2x9kW).

  Equalization of sound is carried out by the devices Klark Teknik DN360 – graphic, 2-way, 30-band-pass, 1/3 octave, analogue with 3U filters and dbx2231.

  Main sound engineer console

  Main (F.O.H.) sound engineer console Soundcraft Live8 “Spirit” – has 24 channels, of which:

  • 22 mono + 2 stereo ins + 6 aux/mix + 8 groups + matrix;
  • 3-way equalizer.

  Sound processing equipment

  Dynamic sound procession equipment and effects processors – by the following manufacturers: dbx, Drawmer, Lexicon MPX ? PCM (compressors, limiters, noise dampers, gates).

  Monitor system

  Monitor system is constituted by a set by JBL of the PX2122 type with power amplifiers of the type Crest Audio 4601.

  Rated capacity – 1kW (2×0,5W).

  Additional equipment

  Bass-guitar combo – Trace Elliot

  Guitar combos – cabinet Trace Elliot

  Key combo: Trace Elliot

  CD-player – “echnics” (Japan) as well as CD- and MD-players “Tascam” (Germany).

  Synchronous translation equipment for the Large and Small Halls

  In the Large and in the Small Hall it is possible to use an infra-red synchronous translation system for 400 subscribers (8 working languages).

  Foyer of the Small Hall Equipment

  • Sound mixing console Soundcraft Spirit;
  • Column loudspeakers “Proel” EK11 1210;
  • Professional effects processor tc electronic M3000;
  • MD- and CD disks player “Tascam”;
  • Professional loudspeaker with an amplifier LSR 25P/2305;
  • Professional amplifier Crest Audio CKV400;
  • Professional equalizer dbx2231;
  • Professional loudspeaker JBL Control 24CT-60;
  • Professional amplifier Crest Audio CK-300.

  Conference Hall equipment

  • Professional loudspeaker JBL Control 28T;
  • Conference system with synchronous translation equipment (2 main consoles, 3 interpreter consoles, 68-mini consoles with headphones for participants).

  Hall of solemn actions equipment

  • 1 Sound mixing console Midas «Venice»;
  • Professional effects processor Yamaha SPX990;
  • Professional crossover dbx 223XL;
  • Professional equalizer XTA GQ600;
  • Professional amplifier Crest Audio;
  • Professional loudspeaker JBL SR47-33X ? SR4718/X;
  • Amplified speakers JBL EON 15P;
  • Rated capacity of the acoustic system – 10kW.

  Mobile acustic complex “Cobra-4”

  The brand new DYNACORD COBRA compact line array system COBRA-4 on the other hand are extremely compact, simple to set up. They therefore provide line array performance in the type of situations where conventional, large format line arrays can offer no economically viable solution.

  The extremely wide horizontal directivity of the DYNACORD COBRA-4 compact line array system (due to their generation of cylindrical sound waves) means they can provide coverage to large audience areas without the comb-filter-like effects that impair the sound quality of conventional horizontal cluster. The shallow and precisely defined vertical directivity, free from strong vertical ?side lobes?, avoids the undesired of sound towards ceiling and floor areas, eliminating to a large extent the interference produced by reflections.

  The active 4-way DYNACORD COBRA-4 compact line array system is designed to project over distances of up to 80 meters in medium-sized marquees, halls and open-air venues and produces SPLs at FOH position, 30 meters from the stage, of 110 db in the medium- and high-frequency ranges and up to 120 db in the bass – the values typically required by a Top Forty band. With the DYNACORD COBRA-4 compact line array system, in the vicinity of the PA, the coverage angle in the high frequency range is particularly wide, to cover the areas directly in front of the stage.
  Total RMS power of system is normalized on a loss 9600W.

  Mobile (touring) complex equipment

  Constituted by the acoustic system set Nexo “Alpha” B2, S2, PS10, PS15 with capacity amplifiers by Camco of the D1 and AD2, DX48, PS10AMP types and output of 40kW.

  Sound missing console – “Yamaha 3500” with 48 in lines, full parametrical equalizer, 8 aux/mix, 8 VCA-line, 12 matrix.

  Sound processing equipment

  Dynamic sound processing systems and effects processors – by the following manufacturers: dbx, XTA, tc electronic, Klark Teknik DN504, Yamaha, Lexicon MPX and PCM (equalizers, compressors, limiters, noise dampers, gates).

  Additional equipment

  Microphones (wire and wireless, Head Sets, clip microphones) by leading world-known manufacturers Shure, AKG, Sennheiser, Electro-Voice, Beyerdinamic are available in a wide selection for sounding of any events.

  Ear monitoring system “Harwood” (transmitters and receivers)

  Video-projecting equipment

  Among video-projecting equipment there are two projectors Panasonic PT-D 7700E on the basis of DLP – light flux technology 7000 ANSI with a set of long-focus and short-focus lenses and a HDV camera. Video may be projected from a DVD-player, from a lap-top to screens of 3x4m size, with direct or reverse projection, there is a device for combining the picture on two projectors.

• 3D cinema complex

  3D CINEMA COMPLEX

  3D cinema complex equipment:

  Christie CP2220 Digital cinema projector

  Lamp Type – CDXL-30SD
  Lamp power – 3 kW
  Luminous flux – 22,000 lumens
  Color rendering – 35.2 trillion. colors
  Contrast ratio – at least 2100:1
  Image format – 2048 x 1080
  Local control system – Touch Panel Touch Panel Controller (TPC)
  Remote diagnostics and management system
  Dimensions, mm – 1181x635x483
  Weight – 116 kg

  Screen MWspol. sr.o.  Maxxscreen 40 premium  Sanora Regent Novalux

  Perforated
  Motorized
  Gain factor – k=1.8
  Size, m – 10×4,2

  Digital cinema server Dolby Digital Cinema system DSS200

  Supported formats: JPEG 2000. MPEG-2

  JPEG 2000
  Bitrate –  250 Mb/s
  Supported frame rates are 23.98, 24, 25, 29.97 and 30 fps

  MPEG-2
  Bitrate –  140 Mb/s
  Supported frame rates are 23.98, 24, 25, 29.97 and 30 fps

  Audio – 16 channels, 8x AES/EBU, balanced
  Delivery key – 2,048-bit decoding
  Decryption of content – 128 bits
  Titration – TI CineCanvas, SMPTE 428-7-2007
  Hard disk – 1300 GB, RAID 5
  Dimensions, mm – 686x483x133
  Weight – 29.5 kg

  Dolby ® CP750 Processor

  Supported formats:  PCM digital, Dolby Digital, Dolby Pro Logic® Dolby Pro Logic II, Dolby Digital Surround EX™, analog audio, Dolby Digital(AC-3).
  PCM channels – 44.1, 48 and 96 kHz, 16.20 and 24 bits, up to eight channels
  The delay control range is 0-250 ms
  Dynamic range – 105 dB
  Distortion – 0.005%
  Three additional digital inputs

  Remote control and monitoring from any computer connected to the cinema network.
  Automatic/manual volume control in real time
  Definition of ASCII commands from intermediate TMS controllers.
  Separate audio output for the hard of hearing
  Dimensions, mm – 432x89x269
  Weight – 4.2 kg

  Digital Cinema Speaker Control Unit / Crossover QSC DCM 10D

  Conversion – 24 bit, 48 kHz, 128x oversampling
  Dynamic range – 103 dB
  Frequency response – 20-20 000 Hz
  Type of inputs – symmetrical
  Dimensions, inches – 19×5,25×15
  Weight – 7.2 kg

  QSC DCA 1222 amplifier – 2 pcs

  Frequency response – 20-20 000 Hz, +/-0.15 dB
  Signal–to-noise ratio – 106 dB
  Distortion – less than 0.01%
  Voltage gain – 32 dB
  Number of channels – 2
  Input impedance – 10kOhm unbalanced
  – 20kohm symmetrical
  Dimensions, cm – 48,3×8,9×35,6
  Weight – 9.5 kg

  QSC DCA 1622 amplifier – 3 pcs

  Frequency response – 20-20 000 Hz, +/-0.15 dB
  Signal–to-noise ratio – 107 dB
  Distortion – less than 0.01%
  Voltage gain – 32 dB
  Number of channels – 2
  Input impedance – 10kOhm unbalanced
  – 20kohm symmetrical
  Dimensions, cm – 48,3×8,9×35,6
  Weight – 9.5 kg

  QSC DCA 2422 Amplifier -1 pc

  Frequency response – 20-20 000 Hz, +/-0.15 dB
  Signal–to-noise ratio – 108 dB
  Distortion – less than 0.02%
  Voltage gain – 32 dB
  Number of channels – 2
  Input impedance – 10kOhm unbalanced
  – 20kohm symmetrical
  Dimensions, cm – 48,3×8,9×35,6
  Weight – 9.5 kg

  Speaker system KCS S-7801 (LCR) – 3 pcs

  Frequency range – 30-20 000 Hz
  Power – 600 W (Lo)/240 W (Mid/Hi)
  Maximum power – 1200W (Lo)/460W (Mid/Hi)
  Dimensions, mm – 1990x630x470
  Weight – 105 kg
  Built-in passive crossover

  Speaker system KCS S-7800 SR-10 (surround) – 16 pcs

  Frequency range – 40-18 000 Hz
  Power – 50 Watts
  Maximum power – 300 watts
  Dimensions, mm – 560x480x290
  Weight – 16 kg
  Separation frequency – 2000 Hz

  Speaker system C -218 A (sub) – 2 pcs

  Frequency range – 20-500 Hz
  Power – 1200 W
  Maximum power – 2400W (Lo)/460W (Mid/Hi)
  Dimensions, mm – 1000x700x720
  Weight – 74 kg
  Separation frequency – 80-110 Hz

  Uninterruptible power supplies

  NeTYS PR 2000 MT – 2000 VA (1340 W), 50/60 Hz, 160-276 V
  Battery life – 8 min
  Dimensions, mm – 2 x (87x415x220)
  Weight – 19 kg

  EATON 9130 UPS – 5000 VA (4500 W) 50/60 Hz, 230 V +10/-15% 160-276 V

  Battery life – 9 min
  Dimensions, mm – 575x242x542
  Weight – 105 kg

  Anti – theft system for 3D glasses
  Sensormatic APS-1002 Dual Pedestal System

  Knight Kristal CW ® 3D Glasses washing and disinfection system

  Dimensions, mm – 1447.8×711.2×715.7
  The maximum lifting height of the door is 1905 cm
  Maximum power consumption – 20 kW
  Total boiler capacity – 18 kW
  Water supply pressure, min/max – 3.04 atm. /5.06 atm.

• Interpreter's booth

  The Audipack Silent 9300 is the most flexible and lightest interpreter booth amongst the available interpreter booth’s.

  The 9300 is a also modular, but a more mobile interpreter booth suitable for 2 persons and is suited to all types of conference system.

  The wall panels easily let themselves install with a single alan key.

  A large working table suitable to carry all needed equipment.

  Have the ventilation units on the roof.

  Benefits:

  • easy installation, can be performed by 1 person
  • good working environment
  • clear view windows (safety glass)
  • cable ducts in the side panels
  • durable build
  • ISO 4043



• Production illumination

  The production lighting complex of Palace of the Republic today can boats the largest and most technically advanced light equipment in Belarus, which combines quality and modern technologies in the sphere of light systems.

  Equipment location scheme of the Big Hall (pdf)

  Light equipment of the Big Hall (jpg)

  • dynamic device (moving head) Coemar Infinity Wash XL – 20 pcs.

  Automated spotlight Coemar Infinity Wash XL designed to create static and dynamic lighting	Power supply	220V/50Hz
  	Power	1400 W
  	Management protocol	DMX 512
  	Number of control channels	22
  	Device weight, kg	36
  	Overall dimensions, mm	450х750х450

  • dynamic device (moving head) Coemar Infinity Spot XL – 22 pcs.

  Automated spotlight Coemar Infinity Spot XL designed to create static and dynamic lighting	Power supply	220V/50Hz
  	Power	1500 W
  	Management protocol	DMX 512
  	Number of control channels	31
  	Device weight, kg	51
  	Overall dimensions, mm	450х505х880

  • dynamic device (moving head) Axcor 900 Profile – 10 pcs.

  LED profile spotlight Axcor 900 Profile designed to create static and dynamic lighting	Power supply	220V/50-60 Hz
  	Power	1400 W
  	Management protocol	DMX 512
  	Number of control channels	38/42
  	Device weight, kg	45
  	Overall dimensions, mm	442х424х674 (874)

  • dynamic device (moving head) VLX Wash – 10 pcs.

  Automated LED floodlight VLX Wash designed to create static and dynamic lighting	Power supply	220V/50Hz
  	Power	840 W
  	Management protocol	DMX 512
  	Number of control channels	23
  	Device weight, kg	28
  	Overall dimensions, mm	422х696х461

  • dynamic device (moving head) Clay Paky A.leda B-EYE K20 – 16 pcs.

  LED spotlight moving head А.LEDA D-EYE K-20 designed to create static and dynamic lighting	Power supply	220V/50-60 Hz
  	Power	800 W
  	Management protocol	DMX 512
  	Number of control channels	21/35
  	Device weight, kg	21
  	Overall dimensions, mm	589х460х395

  • strobe light Martin Atomic 3000 – 4 pcs.

  Strobe light ATOMIC 3000 designed to generate a wide palette of color shades, as well as original visual effects, for example, imitation of flashbulbs and lightning discharges.	Power supply	220V/50-60Hz
  	Power consumption	3000 W
  	Management protocol	DMX 512 or offline mode (stand-alone)
  	Number of control channels	4
  	Device weight, kg	7,5
  	Overall dimensions, mm	245х425х240

  The light is controlled by remote controls:

  • remote control Grand MA 2 full size (manufactured by MA Lighting) – 2 pcs.



  • remote control Grand MA 3 light (manufactured by MA Lighting) – 1 pcs.



  • remote control Grand MA Micro (manufactured by MA Lighting) – 2 pcs.



  • remote control High End Systems Hog4 – 1 pcs.



  • a light control system based on ONPC software (manufactured by MA Lighting) and an NSP block – 1 pcs.



  Portable set of dynamic equipment:

  • dynamic device Vari-Lite VL3500 Spot – 16 pcs.

  Automated searchlight Vari-Lite VL3500 Spot is designed to produce light projections	Power supply	220V/50-60Hz
  	Power	1400 W
  	Management protocol	DMX 512
  	Number of control channels	31
  	Protection degree	IP 20
  	Device weight, kg	41
  	Overall dimensions, mm	457х828х508



  • dynamic device (moving head) Clay Paky Axcor 300 beam – 30 pcs.

  LED floodlight Axcor 300 beam designed to create static and dynamic lighting	Power supply	220V/50-60Hz
  	Power	110W
  	Management protocol	DMX512/RDM/WebServer/ ArtNet
  	Number of control channels	DMX 14/16
  	Device weight, kg	17,6
  	Overall dimensions, mm	345х268х492



  • LED floodlight Clay Paky A.leda B-EYE K20 – 50 pcs. (34 pcs. – portable kit, 16 pcs. – floodlights for staged lighting)

  LED spotlight moving head A.LEDA D-EYE K-20 is designed to create static and dynamic lighting	Power supply	220V/50-60 Hz
  	Power	800 W
  	Management protocol	DMX 512
  	Number of control channels	21/35
  	Device weight, kg	21
  	Overall dimensions, mm	589х460х395



  • dynamic device (moving head) MAC – 250 (manufactured by Martin) – 12 pcs.

  The MAC – 250 spotlight is designed to create static and dynamic lighting	Power supply	220V/50-60 Hz
  	Power	330W
  	Management protocol	DMX 512
  	Number of control channels	14/17
  	Device weight, kg	22,4
  	Overall dimensions, mm	375х538х315



  • dynamic device ColorMix 250 (manufactured by Robe) – 10 pcs.

  The ColorMix 250 spotlight is designed to create static color lighting	Power supply	220V/50-60 Hz
  	Power	330W
  	Management protocol	DMX 512
  	Number of control channels	11
  	Device weight, kg	13
  	Overall dimensions, mm	230х410х390



  • dynamic device ColorWave 300 (manufactured by Clay Paky) – 6 pcs.

  The ColorWave 300 spotlight is designed to create static color lighting	Power supply	220V/50-60 Hz
  	Power	500W
  	Management protocol	DMX 512
  	Number of control channels	2
  	Device weight, kg	13
  	Overall dimensions, mm	374х354х322



  • dynamic device (moving head) Showgun 2000 (manufactured by HI-End) – 6 pcs.

  Dynamic device Shogun 2000 is a powerful controlled spotlight with a set of functions for changing colors, projecting images, switching the optical system (Spot/Wash)	Power supply	220V/50-60 Hz
  	Power	2000 W
  	Management protocol	DMX 512
  	Number of control channels	30
  	Device weight, kg	63,5
  	Overall dimensions, mm	596x639x959



  • architectural lighting spotlight Сity color, 2500 W (manufactured by Studio Due) – 5 pcs.

  The City color architectural lighting spotlight is necessary for lighting decorations, buildings, monuments and any other large objects	Power supply	220V/50-60 Hz
  	Power	2000 W
  	Management protocol	DMX 512
  	Number of control channels	7
  	Device weight, kg	55,0
  	Overall dimensions, mm	780x560x740



  • strobe light LED Clay Paky STORMY CC – 14 pcs.

  Strobe light STORMY CC designed to produce scenic effects of imitation of flashbulbs and lightning discharges, creates the illusion of slow motion	Power supply	220V/50-60Hz
  	Power	850 W
  	Management protocol	DMX 512
  	Number of control channels	7
  	Device weight, kg	7,2
  	Overall dimensions, mm	295х455х155



  • strobe light ATOMIC 3000 (with a ribbon color variator) – 9 pcs.

  Strobe light ATOMIC 3000 designed to generate a wide palette of color shades, as well as original visual effects, for example, imitation of flashbulbs and lightning discharges	Power supply	220V/50-60Hz
  	Power consumption	3000 W
  	Management protocol	DMX 512 or offline mode (stand-alone)
  	Number of control channels	4
  	Device weight, kg	7,5
  	Overall dimensions, mm	245х425х240



  • blinder DTS Flash 2000L (for 2 lamps) – 16 pcs.

  The Blinder 2000 floodlight lamp is designed for static stage lighting	Power supply	220V/50-60Hz
  	Power	1300 W
  	Protection degree	IP 20
  	Management protocol	DMX 512
  	Number of control channels	1
  	Device weight, kg	2,96
  	Overall dimensions, mm	350x235x150



  • blinder DTS Flash 4000L (for 2 lamps) – 12 pcs.

  The Blinder 4000 floodlight lamp is designed for static stage lighting	Power supply	220V/50-60Hz
  	Power	2700 W
  	Protection degree	IP 20
  	Management protocol	DMX 512
  	Number of control channels	1
  	Device weight, kg	4,5
  	Overall dimensions, mm	311х620х220



  • G-Haze fog generator – 4 pcs.

  The G-Haze light fog generator is used to create a light transparent fog that gives a magical atmosphere to a stage show when lighting effects work	Power supply	220V/50Hz
  	Power	800 W
  	Tank capacity	2,0 l
  	Liquid consumption	55-100 ml/h
  	Management protocol	DMX 512
  	Working gas pressure, Mpa	0,35-0,45
  	Device weight, kg	18,2
  	Particle size, microns	0,5-0,7
  	Overall dimensions, mm	700х190х325



  • fog generator HZ-500 Professional Hazer – 2 pcs.

  Generator HZ-500 Professional Hazer designed to create a fog curtain on the stage	Power supply	220V/50Hz
  	Power	480 W
  	Tank capacity	2,5 д
  	Liquid consumption	15 h/l
  	Management protocol	DMX 512
  	Number of control channels	1
  	Device weight, kg	31,5
  	Overall dimensions, mm	490х351х338



  • blower AF-1 (manufactured by JEM) – 4 pcs.

  BlowerAF-1 designed to disperse smoke and fog, direct smoke into chimneys, create wind, as well as to cool equipment	Power supply	220V/50-60Hz
  	Power	175 W
  	Management protocol	DMX 512
  	Number of control channels	1
  	Device weight, kg	10
  	Overall dimensions, mm	390х400х180



  • blower AF-2 (manufactured by JEM) – 2 pcs.

  Blower AF-2 designed to disperse smoke and fog, direct smoke into chimneys, create wind, as well as to cool equipment	Power supply	220V/50Hz
  	Power	245W
  	Management protocol	DMX 512
  	Number of control channels	1
  	Device weight, kg	17
  	Overall dimensions, mm	682х707х318



  • LED floodlight LL-L172A 200W 4 in 1 COB LED wash – 8 pcs.

  LED floodlight LL-L172A 200W 4 in 1 COB LED wash designed for static stage lighting	Power supply	110-240V/ 50-60Hz
  	Power	200W
  	Management protocol	DMX 512
  	Number of control channels	4/8
  	Device weight, kg	7
  	Overall dimensions, mm	370х250х250



  Layout of the equipment of the Small Hall(pdf)

  • • dynamic device (moving head) Mac 250 (manufactured by Martin) – 8 pcs.

    Spotlight MAC – 250 designed to create static and dynamic lighting	Power supply	220V/50-60 Hz
    	Power	330W
    	Management protocol	DMX 512
    	Number of control channels	14/17
    	Device weight, kg	22,4
    	Overall dimensions, mm	375х538х315



    • dynamic device Robe ColorMix 250 – 10 pcs.

    Spotlight ColorMix 250 designed to create static lighting with the ability to change colors	Power supply	220V/50-60 Hz
    	Power	330W
    	Management protocol	DMX 512
    	Number of control channels	11
    	Device weight, kg	13
    	Overall dimensions, mm	230х410х390



    • Floodlight fill light SGM Palco 5 RGB – 10 pcs.

    The Palco 5 RGB full-turn LED spotlight is designed for use in theaters, television studios, during concert and exhibition events.	Power supply	220V/50-60Hz
    	Power	260W
    	Management protocol	DMX 512
    	Number of control channels	8
    	Protection degree	IP55
    	Device weight, kg	13,5
    	Overall dimensions, mm	425х375х229



    • LED floodlight Clay Paky A.leda B-EYE K20 – 5 pcs.

    LED spotlight moving head А.LEDA D-EYE K-20 designed to create static and dynamic lighting	Power supply	220V/50-60 Hz
    	Power	800 W
    	Management protocol	DMX 512
    	Number of control channels	21/35
    	Device weight, kg	21
    	Overall dimensions, mm	589х460х395



    • profile spotlight DS 205 ADB – 8 pcs.

    Spotlight DS 205 ADB designed to create static lighting with the ability to change colors	Power supply	220V/50-60 Hz
    	Power	2000W
    	Color temperature, K	3200
    	Device weight, kg	22,9
    	Overall dimensions, mm	935х500х420



    • spotlight LH 2000 – 17 pcs.

    The LH 2000 spotlight is designed to create static stage lighting	Power supply	220V/50-60 Hz
    	Power	2000W
    	Device weight, kg	23,9
    	Overall dimensions, mm	480х240х310



    • LED floodlight LL-L66 18х15W LED PAR – 8 pcs.

    LED floodlight LL-L66 18х15W LED PAR designed for static stage lighting	Power supply	110-240V/ 50-60Hz
    	Power	18×15 W
    	Management protocol	DMX 512
    	Number of control channels	6/11
    	Device weight, kg	3,7
    	Overall dimensions, mm	220x300x330



• LED Display Panel

  LED Video Display Panel (60 pcs.)
  Dimensions

  Name of the parameter	Value
  The area of the LED tour screen (total)	400,56 m², (1018 modules with a size of 592х666mm)
  Physical pixel pitch, mm	1,85
  Pixel design	LED in SMD housing, RGB 3 in 1, all black LED housing
  Additional protection	Protective coating (according to AOB technology)
  Maximum power consumption,（W/m2）	650
  The maximum power consumption of one module 592х666mm,（W）	280
  Average power consumption (W/m2)	172
  Screen refresh rate, Hz	3840
  Viewing angle, horizontal/vertical, gr.	160/140
  Calibrated screen brightness	800 NIT at a color temperature of 6500K
  Grayscale bit depth, bit	16
  Availability of digital inputs	DVI/HDMI/HDSDI
  Supply voltage	230V±10%, 50Hz
  Conditions of use	Indoor
  Overall dimensions of the module, WxH, mm	592х666
  The weight of the module of two cabinets in a frame 592х666mm,kg	19



  Stacking and suspending attached panels



  Stacking and suspending attached panels
  Weight 22.4 kg
  Max. number of panels per chain. 50
  Lightsource 5mm oval
  Brightness (calibrated) 3000 Nit (candela per square meter)
  Pitch (pixelcenter-to-center) 40mm
  Resolution onepanel 25x50pixels
  Pixels per panel 1250
  Panel frames: aluminum
  LED tubes per panel. 25
  Protection rating. IP 65, NEMA 4
  Pane/interlocking: Prblyte CCS6conicai coupler system
  ACpower 200-240 V nominal, 50/60 Hz
  230V,50Hz 320W,1.5A
  Measurements made at nominal voltage with all LEDs at full intensity. Allow for a deviation of +/-10%.
  Cooling: convection
  Maximum ambient temperature, 50% duty cycle, full white 1 sec. on/1 sec. off 40° C
  Minimum ambient temperature 20°C

  P3-100 processor (3 pcs.)
  Media Server MAXEDIA Broadcast
  Teleview DSC700.10.DV (2 pcs.)

• Video projection equipment

  Multimedia projectors Panasonic PT-D7700E – 2 pcs.



  Nec NP60 multimedia projector. The NP60 projector weighs only 1.6 kg and has ultra-compact dimensions (W x H x D: 246 x 72 x 177 mm). At the same time, the projection brightness is 3,000 ANSI lumens. Numerous “auto functions” such as auto focus, automatic digital correction of trapezoidal distortion, Auto Power Start, Quick Start, Quick Power Off and automatic signal recognition. As an addition, the resolution is XGA (1,024 x 768), high contrast (1,600:1).



  Multimedia projector Optoma ex-765 – 3 pcs.



  Resolution: 1024×768 (XGA),
  Luminous flux 4000 ANSI lumens
  Distance 1.2 m – 10m
  Supported formats: HDTV video (480p, 576p, 720p, 1080i/p),
  SDTV(480i, 576i), Full NTSC, NTSC4.43,
  PAL PAL-M, PAL-N, SECAM,
  HDMI(480i/p, 576i/p, 720p, 1080i/p)
  Lamp power 280 W
  Lamp life 2000 hours
  Dimensions 364 x 283 x 127 mm
  Weight 5.3 kg

  SCREENS

  Producer: DRAPER
  Diagonal(cm/inch): 508/200
  Size (m): 3,1×4,17
  Format: 3:4
  Material: fiberglass
  Type of coating: MW
  Brief description: Folding screen of front and back projection
  Quantity: 2 pcs.

  Motorized Cinematic Motor Screen 300×300

  The surface is matte-white on a fabric basis
  Frontal projection
  Gain 1.1
  Viewing angle 160 degrees
  Case size, cm 340 x 28 x 28
  Weight 34 kg
  Power supply: 220 V, 50 Hz

  The screen body is made of high-strength metal and can be attached to both the wall and the ceiling.

  The case is octagonal in cross-section, covered with white matte paint.

  Back: opaque.

  Video camera Sony DSR-400



  This is a professional video camera with a rigid design and high resolution in low light conditions. This DVCAM-camcorder has many technical properties of cameras of the “higher end” class, such as: full-fledged DSP processing; 65dB S/N (signal-to-noise ratio); minor vertical interference; work with cassettes of both mini and standard size; hybrid LCD panel 2.5 inches.

  Sony HDR-FX1E Video Camera – is capable of recording video in HDV 1080i format. The model is equipped with high-quality Carl Zeiss Vario-Sonnar T optics with an optical image stabilizer, 12x zoom, a wide range of “manual” settings and supports shooting in widescreen mode 16:9. The shooting material is recorded on a standard MiniDV cassette.



  The specialists of the Palace of the Republic are able to implement complex and multicomponent installations in short time according to the customer’s desire. Our personnel will solve your task individually and will offer you the most suitable options for their implementation.

• Lifts and escalators

  In 2000 year in Palace of the Republic 14 elevators and 6 escalators were installed and commissioned. 12 of them are passenger elevators of Finnish production by “KONE” and 2 service elevator made at Sverdlovski elevator construction plant. All escalators are by “OTIS”.

  The installed elevator equipment is serves for the engineering sector of Palace of the Republic, Hall of solemn actions, the cafe, the cinema complex and the President sector.

  Escalators are located on either side of the central entrance and lead from the Small Hall foyer to the Big hall lobbies, then to the Big hall foyer and higher to the Reception Hall . If you have purchased tickets to the gallery of the Big hall, it will be convenient to use the escalators – you get to the gallery straight from the cloakroom. The direction of movement of escalators may change which is indicated at the entrance to the escalator.
